1 ERX-1#sh conf
   2 !
   3 virtual-router default
   4 virtual-router ipv6lac
   5 !
   6 !
   7 aaa domain-map "ipv6_csco"
   8  router-name ipv6lac
   9  ipv6-router-name ipv6lac
  10  tunnel 2
  11   address "10.1.3.1"
  12   source-address "10.1.2.1"
  13   identification ipv6
  14   client-name erx710
  15   server-name kuka
  16   password secret
  17   preference 5
  18 !
  19 aaa domain-map "ipv6_jnpr"
  20  router-name ipv6lac
  21  ipv6-router-name default
  22  tunnel 1
  23   address "10.1.1.1"
  24   identification ipv6
  25   client-name erx710
  26   server-name erx310
  27 !
  28
  29 profile pppoelac
  30  ip unnumbered loopback 0
  31  ip mtu 1492
  32  ppp authentication chap pap
  33 !
  34 virtual-router default
  35 aaa authentication ppp default radius
  36 aaa accounting ppp default radius
  37 !
  38 ip address-pool local
  39 aaa authentication tunnel default radius
  40 aaa accounting tunnel default radius
  41 !
  42 interface gigabitEthernet 4/0
  43  mtu 1522
  44  encapsulation vlan
  45 !
  46 interface gigabitEthernet 4/0.3501
  47  vlan id 3501
  48 !
  49 interface gigabitEthernet 4/0.3502
  50  vlan id 3502
  51  pppoe
  52  pppoe auto-configure
  53  pppoe profile any pppoelac
  54 !
  55 ==============================================================================
  56 virtual-router ipv6lac
  57 aaa authentication ppp default radius
  58 aaa accounting ppp default radius
  59 !
  60 ip address-pool local
  61 aaa authentication tunnel default radius
  62 aaa accounting tunnel default radius
  63 !
  64 interface loopback 0
  65  ip address 10.1.2.1 255.255.255.0
  66  ip rip
  67 !
  68 interface gigabitEthernet 4/0.3501
  69  ip address 10.2.1.2 255.255.255.0
  70 !
  71 ip router-id 10.1.2.1
  72 !
  73 !
  74 router rip
  75  version 2
  76  network 10.1.2.0 255.255.255.0
  77  network 10.2.1.0 255.255.255.0
  78  passive-interface loopback 0
  79 ! End of generated configuration script.
  80 ERX-1#
